Lumina Boxes

quanto os encaixes devem alargar (-80 a 80)

how far the dove tails stick out of/into the edge (multiples of thickness)

radius used on all four corners (multiples of thickness)

from one middle of a dove tail to another (multiples of thickness)

style of the fingers

space at the start and end in multiple of normal spaces

height of the bottom lips sticking out (multiples of thickness) FingerHoleEdge only!

space below holes of FingerHoleEdge (multiples of thickness)

extra material to grind away burn marks (multiples of thickness)

width of the fingers (multiples of thickness)

extra space to allow finger move in and out (multiples of thickness)

space between fingers (multiples of thickness)

width of finger holes (multiples of thickness)

space between the brim and the walls in mm (for flat* lids)

type of handle

type of lid to create

height of the brim in multiple of thickness (for flatbrim lids)

size of the fangs in multiples of thickness (for flatfang lids)

height of the handle in multiples of thickness (if applicable)

height of the brim in multiples of thickness (if any)

play when sliding the lid on in multiples of thickness (if applicable)

size of base in X direction (0=auto)

size of base in Y direction (0=auto)

number of grids in X direction (0=auto)

number of grids in Y direction (0=auto)

height of sidewalls of the tray (mm)

Extra margin around the gridfinity base to allow it to drop into the carrier (mm)

tipo de borda para a borda inferior

edge type for sub panels

The Gridfinity pitch, in mm. Should always be 42.

The cutout for each grid opening. Typical is 38.

The corner radius for each grid opening. Typical is 1.6.

cut pads to be used for gridinity boxes from the grid openings

if pads are cut add holes for magnets. Typical is 6.5, zero to disable,

if magnet hole offset from pitch corners. Typical is 7.75.

The corner radius for each grid opening. Typical is 0.8,

the maximum sized panel that can be cut in x direction

the maximum sized panel that can be cut in y direction

thickness of the material (in mm) 🛈

burn correction (in mm)(bigger values for tighter fit) 🛈

format of resulting file 🛈

label the parts (where available)

print reference rectangle with given length (in mm)(zero to disable) 🛈

width of tabs holding the parts in place (in mm)(not supported everywhere) 🛈

Add a QR Code with link or command line to the generated output

style for inner corners 🛈

spacing around parts (multiples of thickness [: extra space in mm]) 🛈

print surrounding boxes for some structures 🛈
